Key Features

● Innovative GSM&WiFi dual network operating platform. On WiFi network, the alarm system will work without any fee. If no WIFI, it will work on GSM automatically. With industrial grade WIFI module and technology, the system is more stable and safe.

● Supports mobile phone application control (Android and IOS)

● Support 32 wireless zones.

● App check the system in real time: system arm or disarm, sensor low voltage or not ; sensor connect to panel or not.

● Periodic supervision for wireless PIR and magnetic switch

● Window/door open remind

● User account / zone naming

● Built-in buzzer

● 6 private phone Numbers(or mobiles)

Specification

Adapter : input AC 100V-240V 50/60Hz Output DC 5V 1A

Working Voltage : DC 5V

Static working current : < 180mA

Alarm current : < 300mA

Buzzer : 70db(within 1m distance)

Working Temperature : -10℃ ～ +50℃

Communication way : Zigbee/433Mhz/868Mhz(optional)

Wifi module:

Communication Frequency : 2.4GHz-2.5GHz (2400M-2483.5M）

Wireless Standards : IEEE 802.11 b/g/n

GSM module:

GSM frequency : 850/900/1800/1900MHz

Receiving sensitivity : ＜-106dBm

Standby Current : ＜25mA

Receiving Current :＜75mA

Zigbee:

Communication Frequency : 2405MHz-2480MHz

Wireless Standards : IEEE 802.15.4

Receiving sensitivity : ＜-100dBm

Standby Current : ＜50mA

Receiving Current : ＜25mA

Transmitting Current : ＜175mA

433Mhz/868Mhz：

Frequency : 868MHz±0.5MHz 433MHz±0.5MHz

Wireless distance : ≥ 100m (In open area)
